Quality and antioxidant properties of jelly incorporated with corn concentrate

Corn concentrate (CC) (Sunin Co., Chungnam, Korea), gelatin (Samwon, Daegu, Korea), and sugar (CJ, Seoul, Korea) were of commercial grade and were purchased in a local market. The relevant characteristics of CC were as follows: pH 5.89, soluble solids content 6.8 °Brix, and L^*, a^*, and b^*values were 35.90, 7.37, and 2.48, respectively. This commercial CC contained white sugar, starch syrup, CC paste, purified water and salt, flavoring agents, emulsifier, and sodium alginate. All ingredients are generally recognized as safe (GRAS).

The final CC concentration (up to 12%) was determined by several preliminary studies. The jellies were prepared by mixing water, sugar, gelatin, and an appropriate amount of CC: 0, 12, 24, 36, and 48 g of CC was replaced with water depending on the concentration, respectively. First, sugar (30 g) was dissolved in boiling water (200 mL) for 4 min and 200 mL of water with dissolved gelatin for 2 min, after which an appropriate amount of CC was mixed. The final mixture was covered and boiled for 4 min. The mixture was then poured immediately into molds and left for 30 min at room temperature, after which samples were refrigerated at 4℃ for 3 h before the experiments. The samples were warmed at room temperature before each analysis. The standard jellies recipe consisted of 400 mL (100%) of water (without CC served as a control), 30 g of white granulated sugar, and 10 g of gelatin.

Ten grams of sample mixed with 90 mL of distilled water was prepared to measure the pH levels of jelly samples with a pH meter (MP230, Mettler Toledo, Schwerzenbach, Switzerland) at room temperature. The same samples were used to determine total soluble solids (TSS), expressed in °Brix, using an Atago refractometer (PR-201, Atago Co., Ltd., Tokyo, Japan). Moisture content was determined by drying pre-weighed amounts of samples to a constant weight at 105℃ in an oven for 24 h. All measurements were carried out five times, and mean values were compared.

Color was measured in terms of L^*, a^*, and b^* CIE values using a Minolta Spectrophotometer (CM-600d, Minolta Co., Osaka, Japan) equipped with a D65 standard illuminant, an 8 mm aperture, and a 10^o standard observer. The spectrophotometer was calibrated with a standard white calibration cap supplied by the manufacturer. Color values were recorded as L^*, a^*, and b^*values. L^*value represents lightness (0=black, 100=white), a^*value represents the red (+) to green (-) axis, and b^*value represents the yellow (+) to blue (-) axis. Color was measured at the same location (six sides of each cube) using five jelly cubes (3×3×3 cm) for each treatment. Textural characteristics were evaluated by 30% compression of individual samples (3×3×3 cm) with a computer-controlled Advanced Universal Testing System (LRXPlus, Lloyd Instrument Limited, Fareham, Hampshire, UK) at room temperature with a 5 cm diameter stainless steel disc probe. The crosshead speed was 1 mm/s. Twenty samples for each replication were tested, and their mean values were compared.

The DPPH radical scavenging activities of the samples were measured in terms of their hydrogen-donating or DPPH radical scavenging activity. The assay was performed as previously described by Brand-Williams et al. (11) with some modifications. Briefly, 0.2 mM solution of DPPH· radical in ethanol was prepared, after which 5 mL of this solution was added to 1 mL of sample solution in ethanol at different concentrations. The solution was then shaken and left to stand for 10 min. Decolorization of DPPH-donated protons was determined by measuring the absorbance at 517 nm using a spectrophotometer (Optizen 2020 UV Plus, Mecasys Co., Ltd., Daejeon, Korea). DPPH radical scavenging activity was calculated using the following equation:

Spectrophotometric analysis of ABTS⁺· radical scavenging activity was carried out according to the method used by Re et al. (12) with slight modifications. The assay is based on the ability of antioxidants to reduce ABTS⁺· (blue/green) for the generation of ABTS^-2 (colorless). ABTS⁺· cation radical was produced by a reaction between 7.4 mM ABTS in H₂O and 2.6 mM potassium persulfate during storage in the dark at room temperature for 12-16 h. Before use, ABTS⁺· solution was diluted with methanol to obtain an absorbance of 1.1±0.02 at 734 nm. Subsequently, 3 mL of ABTS⁺․ solution was added to 0.1 mL of sample. After 10 min, percent inhibition at 734 nm was calculated for each concentration relative to blank absorbance.

CC jellies were evaluated by 50 consumer panelists. Five samples were presented in random order, and they were asked to evaluate consumer attributes of color, flavor, taste, texture, and overall acceptability. Consumer participants were asked to evaluate preference levels using a nine-point hedonic scale (9=like extremely, 5=neither like nor dislike, and 1=dislike extremely). Each sample (3×3×3 cm), randomly coded using a three-digit number was evaluated in each session. Consumers received a tray containing the samples, a glass of water, and an evaluation sheet. Participants were advised to rinse their palates between samples to minimize residual flavor effects. Enough space was given to handle the samples and questionnaire, and evaluation time was not constrained. No specific compensation was given to the participants.

This study was approved by the Daegu University Institutional Review Board (IRB# 1040621-201711-HR-017-002).

Statistical analysis was carried out using the SAS for Windows version 9.1 (SAS Inst. Inc., Cary, NC, USA). Results were expressed as mean values with the corresponding standard deviation, and significant differences were compared with Duncan’s multiple range test at a 5% level of significance.

Table 1 describes the physical characterization of the jellies supplemented with different levels of corn concentrate (CC). The pH values assessed in jellies ranged from 6.45 to 6.98 and decreased upon addition of an increasing amount of CC (p<0.05). Nevertheless, only minor changes were observed. Similar reduction of pH was observed among jellies incorporated with black garlic concentrate (5) and jujube concentrate (9), probably due to the weak acidic nature of the supplemented concentrate.

Moisture contents of samples ranged from 80.06 to 89.34% (w.b.), and the control sample exhibited the highest moisture content. This range is in good accordance with the values for jellies incorporated with purple sweet potato concentrate (82.03-83.82%) (8) and jujube concentrate (79.56-84.35%) (9). A similar trend has also been reported for jellies supplemented with jujube concentrate (9). Other studies have reported slightly lower ranges of moisture content due to the formulation of ingredients and additives. Moisture contents ranged from 65.22-74.81% and 59.37-62.23% for jellies incorporated with Gastrodia elata concentrate (6) and Rehmannia radix concentrate (7), respectively. Total Soluble solids (TSS) increased significantly with increasing CC concentration (p<0.05). This result is probably attributable to the addition of soluble solids from CC, which showed a TSS of 6.8 °Brix. Similar results were reported for jellies supplemented with black ginseng concentrate (4) and jujube concentrate (9).

Texture analysis found that the hardness of jellies increased significantly as the CC concentration increased (p<0.05). Increased levels of CC remarkably increased the hardness of jellies ranging from 3.47 N at 0% replacement to 5.57 N at 12% replacement. The higher hardness of jellies containing a higher amount of CC could be attributed to lower water holding capacity (8) as well as moisture content. A similar result was reported for jellies incorporated with black ginseng concentrate (4) and purple sweet potato concentrate (8).

Together with texture, surface color is a very important element determining initial acceptability in consumers. Jellies made with CC showed significantly different surface color values compared to the control (p<0.05). L^*values decreased significantly with an increasing amount of CC (p<0.05). On the other hand, a^*and b^*values showed reverse trends, but no significant differences in a^*values were detected among the 9-12% samples or in b^*values among the 3-9% samples. As the concentration of CC in the formulation increased, jellies became darker and more reddish and yellowish (Fig. 1). These results are in accordance with the findings reported for jellies supplemented with purple sweet potato concentrate (8). These results suggest that the color of jellies can be easily controlled based on the concentration of CC according to consumer and/or manufacturer preferences.

Fig. 1. Appearance of jellies with different levels of corn concentrate.

Download Original Figure

Antioxidant activities were investigated based on DPPH radical scavenging activity and ABTS radical cation assay. The usage of CC in the jelly formulation enhanced levels of antioxidant activities (Fig. 2), which can be attributed to the abundant antioxidant capacities of CC. There were significant increases in electron donating ability (EDA) values of bound phenolic extracts in samples containing CC as compared to the control sample (p<0.05). EDA and ABTS values increased significantly with increasing amount of CC added (p<0.05). Sample enriched with 12% CC showed the highest antioxidant potential. Data also showed a positive correlation between the antioxidant capacities of the various samples. EDA increased as ABTS increased.

Fig. 2. DPPH and ABTS radical scavenging activities of jellies with different levels of corn concentrate. Means within the same activity without a common letter are significantly different (p<0.05).

Download Original Figure

Color, flavor, taste, texture, and overall acceptance of control and CC-supplemented jellies were evaluated, and the results are presented as a radar plot (Fig. 3). When evaluated by untrained panelists, statistically significant differences in the attributes tested except for the flavor attribute were detected among samples (p<0.05). The sensory panelists rated the samples enriched with 6% CC as having the highest scores for color, texture, taste, and overall acceptance as compared to other samples (p<0.05). However, further increasing substitution levels had undesirable sensorial effects. On a nine-point hedonic scale, 6% CC sample received average scores in the range of 5.92-6.76, excluding the result for flavor since there was no significant difference among the samples (p>0.05). Considering the 6% CC sample received the highest overall acceptance score (6.40), partial replacement of 6% CC in the jelly formulation seems satisfactory. Similarly, in a study reported by Lee and Ji (10), 6% partial replacement of cranberry concentrate was recommended in the jelly formulation without negatively affecting physical and sensory quality.

Fig. 3. Radar plot of sensory results of jellies with different levels of corn concentrate. Means within the same attribute without a common letter are significantly different (p<0.05).

Download Original Figure

Domestic and international corn markets have been in the spotlight for new renewable energy sources such as bioethanol, but demand for eco-friendly resources is needed to reduce the ratio of simple food and develop technologies in new processing areas. Korea has been a major importer of corn and we should consider better and alternative ways to consume other than eating itself. By taking advantage of the functional properties of CC, it would be a good way to increase overall consumption of corn as well as its processed products such as CC.

In addition, demand for convenient foods such as jelly is rising steadily and if CC is added as a value-added food ingredient to make jelly, it will improve overall quality of jelly. Based on our study, jelly with 6% CC is recommended for developing CC-added jellies with improved overall qualities without sacrificing consumer acceptability.
